AFR 185 Small Block Ford Renegade 20° Street Head
Medium Port, High Velocity, Emission Legal Torque Monster
For the ultimate small block Ford street & track project, you've got to check out AFR's 185cc emissions legal aluminum cylinder heads. Unlike some aftermarket heads, AFR's performance cylinder heads are designed to fit all your stock components. No special parts are required.
Lightweight stainless steel 2.020" intake and 1.600" exhaust valves with 8mm valve stems coupled with profiled 72cc combustion chambers are standard equipment. Fully CNC ported 185cc intake runner volume and 70cc exhaust ports for maximum air flow. AFR's 185 "Renegade" heads are a perfect fit for 302-355 cubic inch engines operating from 1600 to 6400 RPM depending on peripherals. The larger 2.020" intake valves will require aftermarket pistons or flycutting for clearance.
These castings feature AFR's traditional 3/4" thick head deck make these heads ideal for nitrous or forced induction applications. Stud mount style rockers and hardened push rods required on these heads.
NOTE: Stock 5.0L and 5.8L engines must have pistons notched for clearance.
NOTE: Modern hydraulic roller camshaft profiles will typically experience valve float at 6000-6200 RPM with the standard valve springs because of their fast ramp rates and higher valve lift. It is highly recommended to upgrade to the optional higher pressure dual valve springs to reduce chances of valve float associated with 6200 RPM or higher. We can also fit your heads with PAC Racing, Lunati or our own severe duty springs for an additional cost. High RPM applications should also use tool steel or titanium retainers and the ARP 7/16" rocker studs.
FlowTech Induction can provide a custom built cylinder head package without the high price!
PART NUMBER: AFR-1420
Due to the ever increasing costs and limited availability of certain materials, skyrocketing shipping costs, credit card usury fees as well as the inept policies of the current administration, we can no longer provide set pricing on any products on this web site. Email directly at info@FlowTechInduction.com for the latest pricing and availability.
