AFR 195 SB Ford Renegade Cylinder Heads - (72cc)
Medium Runner, High Velocity Cylinder Head - "emissions legal"
Air Flow Research's mid-range 195cc Renegade Ford cylinder head adds more depth to their already strong lineup. This medium runner cylinder head almost defies the law of physics flowing a whopping 315 CFM from a modest sized intake port. The 195 Ford head comfortably outflows its 10cc larger predecessor and is on the heels of our previous best small block Ford inline valve head. If you want the maximum emission legal street/strip horsepower small block Ford head, check out these all new 195cc emissions legal (CARB EO #250-3) performance cylinder heads.
The AFR 195 series heads utilize 2.050" diameter intake valves and 1.600" exhaust valves with lightweight 8mm stems. Standard combustion chamber volume is 72cc. Milling the decks for smaller than standard chamber volumes optional and at an additional charge. Exhaust port and header bolt pattern are raised .125" higher than stock for better flow, though this rarely affects header or chassis fitment. Dual bolt pattern header fastening standard so you can use a more race oriented header without adapters. The usual .750" nominal deck thickness makes these 195 heads ideal for high compression, nitrous or blower applications. Stud mounted rocker arms are required. Will not accept OEM style pedestal rocker arms.
If you're looking for the ultimate small block Ford powered dual purpose race car, you've got to check out these AFR 195 Renegade "Competition Series" aluminum cylinder heads. Unlike some aftermarket heads, AFR performance cylinder heads are designed to fit all your stock components and no special parts are required.
NOTE: The larger 2.050" intake valves will require aftermarket pistons or flycutting for clearance. AFR's severe duty #8019 dual valve springs standard equipment. (155#/410# - max lift .650"). Optional PAC Racing, Lunati and FTI severe duty valve springs available. Titanium intake and inconel exhaust valves also available at an additional charge. Extra long ARP rocker studs for stud girdles or large trunnion rocker arms are optional. Contact us directly for information and pricing on any custom built heads.
These AFR Renegade 195cc Ford cylinder heads are designed for predominately for 331-392 cubic inch engines operating from 2000 RPM to 7000 RPM. Range will vary depending on application and peripherals used.
AFR 195 CYLINDER HEADS FEATURE:
2.050" x 8mm Stainless Intake Valves
1.600" x 8mm Stainless Exhaust Valves
72cc Combustion Chamber
Heavy Duty AFR #8019 Dual Valve Springs
ARP Pro Series 7/16" Rocker Studs
NOTE: Stock 5.0L and 5.8L engines must have pistons notched for clearance.
PART NUMBER: AFR-1428-716
