AFR 205 SB Ford Renegade Series Cylinder Heads - (72cc)

Powerful Standard Configuration Street/Strip Head

If you’re looking for the world’s finest street/track cylinder small block Ford cylinder head available, AFR’s 205 Renegade series is your answer. These heads utilize lightweight 8mm stem x 2.080" diameter intake and 1.600" diameter exhaust valves with PAC Racing solid roller valvetrain. This cylinder head moves a tremendous volume of quality air flow through conservative runner volume delivering big torque and horsepower numbers. Dual quench pad design with the larger 72cc combustion chamber for lowering static compression, also provides amazing mid and high lift air flow.

Design features include fully CNC ported 205cc volume intake runners and 70cc exhaust ports which are raised .125" higher than stock. AFR’s trademark 3/4” thick head deck makes them ideal for heavy nitrous or forced induction applications. These 72cc heads can be milled to lower the chamber sizes for an additional charge.

The AFR 205 small block Ford cylinder heads can also be fitted with multiple valvetrain packages including many hydraulic roller valve spring options. Contact us directly through Email for information and pricing on any of these options.

The new 205 Renegade Race is the ultimate choice for 327-408+ cubic inch engines operating from 3500 to 7200 RPM depending on camshaft profile and peripherals.

NOTE: The 2.080" valves require aftermarket pistons notched for valve clearance

PART NUMBER: AFR-1458
