DSR Dual Valve Spring Tool Steel Kit - (Twisted Wedge)
For those performance minded street racers using the Trickflow "Twisted Wedge" FAC 170 cylinder heads, there is now a more affordable, top quality, dual valve spring kit featuring lightweight TOOL STEEL retainers, hardened valve spring locators, machined valve locks and Viton seals that safely provides more valvetrain control.
This DSR "Twisted Wedge" spring kit features the popular small diameter, dual valve springs with the required seat and open load pressures for most dual purpose hydraulic roller camshaft profiles with maximum lift of .650” at the valve. The dual valve springs used in these DSR kits are the same Associated Spring brand pieces used in many of the current performance spring packages. This DSR kit comes complete and is ready to easily install into your early Twisted Wedge, newer FAC 170 and the original FAC 190 heads.
This high performance, valve spring package incorporates US manufactured, FEA designed, TOOL STEEL retainers, not inferior overseas junk. Fully CNC machined for use in severe duty applications such as endurance, road racing and marine uses. Hardened, fully machined spring locators are included and accurately locate the spring assembly to the valve guide, preventing scuffing on the aluminum castings. High strength, hardened "machined" (not stamped) steel valve locks are provided for valve stem holding reliability. Premium quality, Viton steel shell valve stem seals are included for proper valve stem lubrication and oil control.
VALVE SPRING DATA:
- Outer spring outside diameter: 1.305"
- Inner spring inside diameter: 0.670"
- Maximum recommended lift: .650"
- 153# at 1.800" Installed Height
- 420# at 1.150" Open Pressure
- Spring rate: 410#/inch
- Coil bind: 1.100"
Part Number: DSR-TLS-KIT-TW
