Edelbrock High Flow Intake Elbow - 95mm Throttle Body
These elbows are designed for use in high horsepower extreme street and racing applications. An internal divider optimizes flow distribution to all ports of the manifold by reducing turbulence. High Flow Elbow #3849 is an ultra high flow version which measures 4.50" from flange to throttle body centerline (7.75" overall height). During flow testing this elbow provided up to 1,050 CFM with a 90mm throttle body and 1,150 CFM with a 95mm throttle body.
* Does not accept LS1 throttle bodies *
Notes:
- Throttle bore center sits 9.00" forward & .56" up from the manifold mounting flange
- Includes throttle body adapter plate #2737 for use with LS1 throttle bodies
- Edelbrock 90mm throttle body #3869 recommended for optimum performance.
Intake Elbow Dimensions:
- Length (Throttle Body Centerline to Intake Flange Centerline): 9.00"
- Bore Centerline: 0.56"
- Overall Height: 3.62"
- Throttle Body Flange Angle: 102°
PART NUMBER: EDE-3847
