Edelbrock LS3 Super Victor Manifold - (LS3-L92 4500)
The race proven Super Victor series of intake manifolds from Edelbrock are a sure fire way for your performance engine to make even more horsepower. This brand new Super Victor is specifically designed for Gen IV LS engines equipped with rectangular port LS3/L92 style cylinder heads and a "4500 series" Dominator carburetor. Coupled with the proper camshaft design and valvetrain peripherals, this manifold has an operating between 3,500-7,500+ RPM, depending on displacement and application.
The Super Victor LS3/L92 intake manifold uses a standard square bore Dominator carb flange that is compatible with Holley 4500 series four barrel carburetors or throttle bodies. This manifold can be fitting with EFI and/or nitrous bungs for additional cost. Contact us directly for information.
These new Super Victor intake manifolds are designed with 24% larger runners than the Victor Jr. #28457 along with a larger 4500 style plenum. The larger plenum volume makes these intake manifolds ideal for nitrous and forced induction applications. They also feature tapered runners for increased flow at high RPM. This new Super Victor 4500 series manifold can accommodate throttle bores up 2.250” diameter.
- Uses LS3-L76-L92 style individual port O-ring seals
- Recommended intake gasket - Chevrolet Performance 19256623
- Carb pad height: 7.67'' measured from valley cover
- Intake manifold only - hardware and gaskets not included.
- Port exit dimensions: 1.27" x 2.58"
PART NUMBER: EDE-2821
