Edelbrock Super Victor II Intake Manifold - (GEN 1)
CHEVROLET 262-400 SMALL-BLOCK V8
This small-block Chevy manifold is designed to work with modern high flowing 23° heads on large cubic inch applications. The runner area at the plenum is 25% larger than our Super Victor #2925, and the port exits are sized for use with a Fel-Pro #1206 intake gasket. Modern casting techniques create smooth, thin and extended divider walls for "out-of-the-box" performance. Just port match (up to #1207 - 1.38" x 2.28") and go. This intake is machined for 4150 style carburetors.
SPECIFICATIONS:
- Standard Deck Small Block Chevy
- 4150 Style Square Bore Carb Flange
- Standard Intake Port Size & Location
- Approximately 4000-8000 RPM Range
* Some applications will require hood modification *
FEATURES:
- Port Exit Dimensions: 1.18'' w x 2.08'' h
- Bolt hole centerline to port roof: 0.940''
- Bolt hole centerline to port floor: 1.160''
- Carburetor Pad Height: 6.75'' from end rails
- Carburetor Pad Angle: 0° from flange
- Recommended Intake Gasket: FelPro HP 1206
PART NUMBER: EDE-2892
