AFR 195 SBF Renegade Non-Emission Cylinder Heads - 58cc

Air Flow Research

Email for pricing

(No reviews yet) Write a Review
SKU:
AFR-1381-716

AFR 195 SB Ford Renegade Competition 20° Head - (58cc)

Medium Runner, High Velocity "Non-Emissions" Cylinder Head

AirFlow Research's mid-range 195cc Renegade Ford cylinder head adds more depth to their already strong lineup. This medium runner cylinder head almost defies the law of physics flowing a whopping 315 CFM from a modest sized intake port. The 195 Ford head comfortably outflows its 10cc larger predecessor and is on the heels of our previous best small block Ford inline valve head. These heads do not have EGR or AIR ports so they are not legal for emissions requirements.

The AFR 195 series heads utilize 2.050" diameter intake valves and 1.600" exhaust valves with lightweight 8mm stems. Standard combustion chamber volume is 58cc. Milling the decks for smaller than standard chamber volumes optional and at an additional charge. Exhaust port and header bolt pattern are raised .125" higher than stock for better flow, though this rarely affects header or chassis fitment. Dual bolt pattern header fastening standard so you can use a more race oriented header without adapters. The usual .750" nominal deck thickness makes these 195 heads ideal for high compression, nitrous or blower applications. Stud mounted rocker arms with 7/16" poly-locks are required. Will not accept OEM style pedestal mounted rocker arms.

If you're looking for the ultimate small block Ford powered dual purpose race car, you've got to check out these AFR 195 Renegade "Competition Series" aluminum cylinder heads. Unlike some aftermarket heads, AFRs performance cylinder heads are designed to fit all your stock components and no special parts are required.

NOTE: The larger 2.050" intake valves will require aftermarket pistons or fly-cutting for clearance. AFR's severe duty #8019 dual valve springs standard equipment. (155#/410# - max lift .650"). Optional PAC Racing, Comp Cams and FTI severe duty valve springs available. Titanium intake and inconel exhaust valves also available at an additional charge. Extra long ARP Pro-Series rocker studs for stud girdles or large trunnion rocker arms optional. Contact us directly for information and pricing on any custom built heads.

These AFR Renegade 195cc Ford cylinder heads are designed for predominately for 331-392 cubic inch engines operating from 2000 RPM to 7000 RPM. Range will vary depending on application and peripherals used.

AFR 195 CYLINDER HEADS FEATURE:
2.050" x 8mm Stainless Intake Valves
1.600" x 8mm Stainless Exhaust Valves
58cc Combustion Chambers
Heavy Duty AFR #8019 Dual Valve Springs
ARP Pro Series 7/16" Rocker Studs

NOTE: Stock 5.0L and 5.8L engines must have pistons notched for clearance.

PART NUMBER: AFR-1381-716
