Edelbrock LS1 Victor Jr. Manifold - (LS1-LS2 4150)
This race proven Edelbrock Victor Jr. series intake manifold is designed for GEN 3 LS engines equipped with cathedral port, LS1/LS2/LS6 cylinder heads and a 4150 series carburetors. Coupled with the proper camshaft design and valvetrain peripherals, this manifold has an operating between 3,500 - 7,500 RPM, depending on displacement.
This Edelbrock Victor Jr. LS1 intake manifold is a mid-range height, single plane design capable of supporting up to 600 HP. This manifold also include a throttle bracket designed to work with 700R-4, 200R-4 and Turbo 350 transmissions. Most applications will require hood modification.
FEATURES:
Standard square bore flange that is compatible with 4150 series four barrel carburetors.
For recommendations, contact us via Email.
- Uses LS1-LS6-LS2 style individual port O-ring seals
- Recommended intake gasket - Chevrolet Performance 19256623
- Carb pad height = 7.40'' measured from valley cover
- Intake manifold only - hardware and gaskets not included.
PART NUMBER: EDE-29087
