Edelbrock Victor Jr Intake Manifold - (GEN 1)
These versatile intake manifolds are excellent for many applications from high performance street to hardcore track racing. They provide maximum performance for engines with standard intake port locations whether iron or aluminum cylinder heads. The low profile of the Edelbrock Victor Jr #2975 works well in applications with minimal hood clearance and where one or two inch carb spacers can be used for performance tuning.
All Edelbrock Victor Jr. small block Chevrolet intake manifolds offer extra material added for port matching and customizing. Standard Holley 4150 square bore carburetor flange with water crossovers drilled and tapped for temp senders or bypass holes are standard.
SPECIFICATIONS:
- Standard Deck Small Block Chevy
- 4150 Style Square Bore Carb Flange
- Standard Intake Port Size & Location
- Approximately 3200-7500 RPM Range
* Some applications will require hood modification *
FEATURES:
- Port Exit Dimensions: 1.10'' w x 1.90'' h
- Bolt hole centerline to port roof: 0.800''
- Bolt hole centerline to port floor: 1.100''
- Carburetor Pad Height: 4.58'' from end rails
- Carburetor Pad Angle: 3° from flange
- Recommended Intake Gasket: FelPro HP 1205
PART NUMBER: EDE-2975
