Edelbrock Victor Jr. EFI Intake Manifold - (Ford 4.6 2V)
The Edelbrock #28385 Victor Jr. intake manifold is designed for Ford 4.6L SOHC Modular engines. This 1999-2004 SOHC Modular 4.6L manifold was designed for 4.6L Fords using EFI in racing applications.
Timing control module available separately. Not intended for or as a stock replacement intake manifold.
Whether you're building an ultra high performance street machine or all out race car, this Edelbrock intake manifold will provide the power right where you want it. The Edelbrock Victor Jr. Ford 4.6L SOHC also features a natural aluminum finish for a classic look. For the ultimate "Made in USA" quality, every Edelbrock intake manifold is cast and machined in the USA.
TheVictor Jr. 4.6L manifold is sure to open the door for competition level performance. Capable of supporting up to 600 horsepower, the single plane design was engineered with a race proven short runner layout for improved airflow in the 3500-7500 RPM range.
Fuel rail: Edelbrock #3639
Intake gasket: OEM factory gaskets
Throttle body: Edelbrock #38783 4150 style 4V or #3848 competition EFI elbow and #3818 90mm throttle body.
Manifold height: A-4.75", B-4.75", 0 Deg carb angle
Port exit dimensions: 1.42" x 1.72"
Throttle pad and plenum optimized for square-bore (4150 style) four barrel throttle bodies.
Built in water crossover with clearance for the stock 1999-2004 alternator location.
RPM RANGE: 3500-7500 RPM+
PART NUMBER: EDE-28385
